MI01002112
Electromagnetic flow Sensor DN125 MI01, Hard rubber VHE/102, 18-36V
- Delivery time
- 5 - 6 weeks
Equipment
flange seal DN125 PN10/16 141x192x2 Klingersil C 4400
€7.26 VAT included.
joint set flange/flange DN125 - 5" Inch for flange PN10/16/25 stainless steel
€20.94 VAT included.
tee (welded) 139,7 x 3,0 stainless steel 1.4571
€251.92 VAT included.
Welding neck flange DN125 PN10/16 EN1092-1 11 B1 1.4541
€117.45 VAT included.
pipe bend (welded) 90° 139,7 x 2,0 stainless steel 1.4571
€115.67 VAT included.
Questions about the article?
Our employee Max Eisele
will be happy to help you
NIERUF-SERVICE
Electromagnetic flow Sensor DN125 MI01, Hard rubber VHE/102, 18-36V
Electromagnetic flow Sensor DN125 Flange DIN 2501 PN16 remote version design, lining of measuring pipe made of Hard rubber VHE/102 18-36V
| product | Electromagnetic flow Sensor |
|---|---|
| type | MI01 |
| manufacturer | NieRuf |
| diameter | DN125 |
| connection | Flange DIN 2501 PN16 |
| design | remote design |
| measuring tube | stainless steel 1.4301 |
| solenoid chamber | steel |
| flange | steel |
| coating | Primer: Coating thickness: min. 50 mu, top coat: layer thickness: min. 120 mu RAL 5015 |
| lining of measuring pipe | Hard rubber VHE/102 |
| electrodes | stainless steel 1.4571 |
| error of measurement | +/- 0,5% of the reading from 0,25 ms to 10m/s |
| repeat accuracy | +/- 0,15% of the reading from 0,25 ms to 10m/s |
| operqting temerature | +90°C |
| protection class | IP67 |
| minimum conductivity media | > 20 μS/cm |
| max. flow rate | 10 m/s |
| flow rate final value | 0,25 - 10 m/s |
| flow rate range | 11,04 - 441,79 m3/h |
| wiring | 2 x M16 x 1,5 |
| wire | magnetic current cable (3x1,0 mm2) and electrode cable (5x0,5 mm2), length 5 m |
| power supply | 18-36V |
| analogue output | 4 - 20mA |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
Electromagnetic flow Sensor DN125 MI01, Hard rubber VHE/102, 18-36V
Article no.
: MI01002112
product:
Electromagnetic flow Sensor
type:
MI01
manufacturer:
NieRuf
diameter:
DN125
connection:
Flange DIN 2501 PN16
design:
remote design
measuring tube:
stainless steel 1.4301
solenoid chamber:
steel
flange:
steel
coating:
Primer: Coating thickness: min. 50 mu, top coat: layer thickness: min. 120 mu RAL 5015
lining of measuring pipe:
Hard rubber VHE/102
electrodes:
stainless steel 1.4571
error of measurement:
+/- 0,5% of the reading from 0,25 ms to 10m/s
repeat accuracy:
+/- 0,15% of the reading from 0,25 ms to 10m/s
operqting temerature:
+90°C
protection class:
IP67
minimum conductivity media:
> 20 μS/cm
max. flow rate:
10 m/s
flow rate final value:
0,25 - 10 m/s
flow rate range:
11,04 - 441,79 m3/h
wiring:
2 x M16 x 1,5
wire:
magnetic current cable (3x1,0 mm2) and electrode cable (5x0,5 mm2), length 5 m
power supply:
18-36V
analogue output:
4 - 20mA
