AV03020009
Globe valve DN 65 AV03 cast steel 1.0619+N regulation cone
- Delivery time
- 1 - 2 weeks
Equipment
flange seal DN65 PN10/16/25/40 77x127x2 Klingersil C 4400
€4.28 VAT included.
joint set flange/flange DN65 - 2 1/2" Inch for flange PN40 steel
€9.52 VAT included.
Questions about the article?
Our employee Max Eisele
will be happy to help you
Globe valve DN 65 AV03 cast steel 1.0619+N regulation cone
Globe valve DN 65 in straight through with bellow material cast steel 1.0619+N authorization TA-Luft regulation cone
| product | Globe valve |
|---|---|
| type | AV03 |
| manufacturer | NieRuf |
| diameter | DN 65 |
| flange | flange acc. DIN EN 1092 |
| pressure | PN40 |
| seal | metal |
| media | liquid and gaseous media |
| temperature | to max +450°C - depending on working pressure |
| pressure range | max. 40 bar depending on operating temperature |
| design | straight through with bellow |
| body material | cast steel 1.0619+N |
| material spindel unit | cast steel 1.0619+N |
| handwheel | steel with cataphoretic-coating (non-rising) |
| plug | regulation cone |
| bellow | stainless steel 1.4571 |
| length | acc DIN EN 558 series 1 |
| approval | EN ISO 15848-1 / TA Luft TÜV-Prüf-Nr: TA 07 2016 C04 |
| installation position | any position, spindle preferably vertical |
| product feature | Stop valve - straight through with flanges and bellows seal additionally with non-rotation lock, flat lubricating nipple and position indicator as standard - CLOSED / OPEN. |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
Globe valve DN 65 AV03 cast steel 1.0619+N regulation cone
Article no.
: AV03020009
product:
Globe valve
type:
AV03
manufacturer:
NieRuf
diameter:
DN 65
flange:
flange acc. DIN EN 1092
pressure:
PN40
seal:
metal
media:
liquid and gaseous media
temperature:
to max +450°C - depending on working pressure
pressure range:
max. 40 bar depending on operating temperature
design:
straight through with bellow
body material:
cast steel 1.0619+N
material spindel unit:
cast steel 1.0619+N
handwheel:
steel with cataphoretic-coating (non-rising)
plug:
regulation cone
bellow:
stainless steel 1.4571
length:
acc DIN EN 558 series 1
approval:
EN ISO 15848-1 / TA Luft TÜV-Prüf-Nr: TA 07 2016 C04
installation position:
any position, spindle preferably vertical
product feature:
Stop valve - straight through with flanges and bellows seal additionally with non-rotation lock, flat lubricating nipple and position indicator as standard - CLOSED / OPEN.
